Typical Lead time is 1-2 weeks, but varies based on demand.
Unit of Measure

Specifications

Brands

 N/A GTek Automation

Direct Current (DC) Rated Voltage

 N/A 24 V

Attainable Vacuum

 N/A -66.6 kPa-500 mmHg-666 mbar-19.7 inHg
Free Air Displacement1 N/A 2.8 L/min0.1 ft³/min

Maximum Pressure

 N/A 250 kPa2.5 bar36.25 psig2.5 psi

Maximum Current

 N/A 0.95 A

Straight Nipple Inlet and Outlet Outside Diameter (OD)

 N/A 5 mm

Coil Insulation Class

 N/A E or its Equivalent (JETL)

Gross Weight

 N/A 0.80 lb0.36 kg

Rated Operating Time

 N/A 30 min

Working Pressure Range

 N/A -66.6 to 100 kPa-666 mbar to 1 Bar -500 mmHg to 1 kgf/cm² -19.7 inHg to 14.5 psig

Leadwire Length

 N/A 14-3/16 in360 mm

Box Size

Box Length

 N/A 12 in

Box Width

 N/A 9 in

Box Height

 N/A 9 in

Dimensions

Length

 N/A 1-21/32 in42 mm

Width

 N/A 1-31/32 in24.5 mm

Applications

Applications

 N/A Film Cutter Vending Machines

Note

Note

 N/A Ask your distributor for appropriate operation of both compression and vacuum in the same one pump.

Please read the page of "How to Use This Catalog" first for correct use of compressors and pumps.
  • 1 Air displacement at no-load operation.
