Typical Lead time is 1-2 weeks, but varies based on demand.
Unit of Measure
Specifications
Brands |
N/A GTek Automation |
Direct Current (DC) Rated Voltage |
N/A 24 V |
Attainable Vacuum |
N/A -26.7 kPa-200 mmHg-267 mbar-7.87 inHg |
Free Air Displacement1 | N/A 7 L/min0.247 ft³/min |
Maximum Pressure |
N/A 45 kPa0.45 kgf/cm²0.45 bar6.52 psig |
Maximum Current |
N/A 0.5 A |
Life Expectancy |
N/A 5,000 h |
Straight Nipple Inlet and Outlet Outside Diameter (OD) |
N/A 6 mm |
Coil Insulation Class |
N/A E or its Equivalent (JETL) |
Gross Weight |
N/A 0.55 lb0.25 kg |
Rated Operating Time |
N/A Continuous |
Working Pressure Range |
N/A -26.7 to 45 kPa-267 mbar to 0.45 bar -200 mmHg to 0.45 kg/cm² -7.87 inHg to 6.52 psig |
Leadwire Length |
N/A 15-3/4 in400 mm |
Measure System |
N/A EURO SI U.S.A |
- 1 Air displacement at no-load operation.
