Unit of Measure
Specifications
Brands |
N/A GTek Automation |
Direct Current (DC) Rated Voltage |
N/A 24 V |
Maximum Pressure |
N/A 80 kPa0.8 bar0.8 kgf/cm²11.6 psig |
Hose Barb Outlet Outside Diameter (OD) |
N/A 6 mm |
Pressure Rating |
N/A 50 kPa0.5 kgf/cm²0.5 bar7.25 psig |
Rated Airflow1 | N/A 2.5 L/min0.088 ft³/min |
Current (Mean Value) |
N/A 0.35 A |
Life Expectancy Mean Time to Failure (MTTF) |
N/A 10,000 h |
Duty Cycle |
N/A Continuous |
Coil Insulation Class |
N/A A or its equivalent |
Gross Weight |
N/A 2.01 lb0.91 kg |
Leadwire Length |
N/A 11-13/16 in300 mm |
Measure System |
N/A EURO SI U.S.A |
- 1 Air displacement at rated pressure.
