Typical Lead time is 1-2 weeks, but varies based on demand.
Unit of Measure
Specifications
Brands |
N/A GTek Automation |
Pressure Rating |
N/A 100 kPa1.0 kgf/cm²1.0 bar14.5 psig |
Rated Airflow |
N/A 16 L/min0.565 ft³/min |
Power Consumption |
N/A 85 W90 W |
Rated Frequency |
N/A 60 Hz |
Life Expectancy Mean Time to Failure (MTTF) |
N/A 3,000 h |
Outlet |
N/A International Organization for Standardization (ISO) Rc 1/4 |
Duty Cycle |
N/A Continuous |
Coil Insulation Class |
N/A E or its equivalent (JETL) and B for UL |
Leadwire Length for 115 Volt (V) Voltage |
N/A 5-7/8 in150 mm320 mm |
