Typical Lead time is 1-2 weeks, but varies based on demand.
Unit of Measure
Specifications
Brands |
N/A GTek Automation |
Attainable Vacuum |
N/A -80 kPa-600 mmHg-800 mbar-23.6 inHg |
Note for Attainable Vacuum |
N/A Operations at higher than -80kPa need an additional leak valve or relief valve on the inlet piping. |
Free Air Displacement |
N/A 25 L/min0.88 ft³/min |
Power Consumption |
N/A 70 W |
Rated Frequency |
N/A 60 Hz |
Life Expectancy Mean Time to Failure (MTTF) |
N/A 6,000 h |
Inlet |
N/A International Organization for Standardization (ISO) Rc 1/4 |
Outlet |
N/A International Organization for Standardization (ISO) Rc 1/4 |
Duty Cycle |
N/A Continuous |
Coil Insulation Class |
N/A E or its equivalent (JETL) and B for UL |
Weight per Each |
N/A 11 lb5 kg |
Leadwire Length |
N/A 5-7/8 in300 mm600 mm |
